The Frontend used by the user interfaces for VolD. More...

Collaboration diagram for de.zib.vold.frontend.Frontend:

Public Member Functions
	Frontend ()
	Construct an uninitialized Frontend.
void	setVolatileDirectory (VolatileDirectory volatileDirectory)
	Set the volatile directory to store the informations in.
boolean	getRecursiveScopeLookups ()
	Are recursive scope lookups enabled?
void	setRecursiveScopeLookups (boolean recursiveScopeLookups)
	Enable/disable recursive scope lookups.
boolean	getPrefixLookupsAllowed ()
	Are prefix lookups allowed?
void	setPrefixLookupsAllowed (boolean prefixLookupsAllowed)
	(Do not) allow prefix lookups.
void	insert (String source, Key key, Set< String > value)
	Insert a key.
void	refresh (String source, Key key)
	Refresh a key.
void	delete (String source, Key key)
	Delete a key.
Map< Key, Set< String > >	lookup (Key key)
	Lookup the specified key.
Protected Member Functions
void	checkState ()
	Internal method which acts as part of the guard of all public methods.
Package Attributes
final String	scopeDelimiter = "/"
Private Member Functions
String	prepare_prefix_key (String key)
	Prepare key for (prefix-) lookup.
String	scope_base (String scope)
	Get the parent of a scope.
Map< Key, Set< String > >	scopeLookup (Key key)
	Lookup the specified key only in the given scope.
Private Attributes
final ReentrantReadWriteLock	rwlock
VolatileDirectory	volatileDirectory
boolean	recursiveScopeLookups
boolean	prefixLookupsAllowed
Static Private Attributes
static final Logger	log = LoggerFactory.getLogger( Frontend.class )

Detailed Description

The Frontend used by the user interfaces for VolD.

This class implements the key/value logic offered by VolD: Each key stored on the volatile directory is associated with a source. When a key will be inserted from two different sources, a lookup for that key will result in the merged set of values. A Deletion or freshening of a key is associated with a certain source, thus just a part of the values will deleted or renewed.

See also:: Key

Definition at line 30 of file Frontend.java.

Constructor & Destructor Documentation

de.zib.vold.frontend.Frontend.Frontend ( )

Construct an uninitialized Frontend.

Definition at line 46 of file Frontend.java.

References de.zib.vold.frontend.Frontend.rwlock, de.zib.vold.frontend.Frontend.setPrefixLookupsAllowed(), de.zib.vold.frontend.Frontend.setRecursiveScopeLookups(), and de.zib.vold.frontend.Frontend.volatileDirectory.

Here is the call graph for this function:

Member Function Documentation

void de.zib.vold.frontend.Frontend.checkState ( ) [protected]

Internal method which acts as part of the guard of all public methods.

Definition at line 107 of file Frontend.java.

References de.zib.vold.frontend.Frontend.volatileDirectory.

Referenced by de.zib.vold.frontend.Frontend.delete(), de.zib.vold.frontend.Frontend.insert(), de.zib.vold.frontend.Frontend.lookup(), and de.zib.vold.frontend.Frontend.refresh().

Here is the caller graph for this function:

void de.zib.vold.frontend.Frontend.delete	(	String	source,
		Key	key
	)

Delete a key.

Parameters:

source	The source for which the key should be deleted.
key	The key to delete.

Definition at line 205 of file Frontend.java.

References de.zib.vold.frontend.Frontend.checkState(), de.zib.vold.volatilelogic.SlicedDirectory.delete(), de.zib.vold.frontend.Frontend.log, de.zib.vold.frontend.Frontend.rwlock, and de.zib.vold.frontend.Frontend.volatileDirectory.

Referenced by de.zib.vold.userInterface.RESTController.post().

Here is the call graph for this function:

Here is the caller graph for this function:

boolean de.zib.vold.frontend.Frontend.getPrefixLookupsAllowed ( )

Are prefix lookups allowed?

Definition at line 88 of file Frontend.java.

References de.zib.vold.frontend.Frontend.prefixLookupsAllowed.

Referenced by de.zib.vold.frontend.Frontend.scopeLookup().

Here is the caller graph for this function:

boolean de.zib.vold.frontend.Frontend.getRecursiveScopeLookups ( )

Are recursive scope lookups enabled?

Definition at line 68 of file Frontend.java.

References de.zib.vold.frontend.Frontend.recursiveScopeLookups.

Referenced by de.zib.vold.frontend.Frontend.lookup().

Here is the caller graph for this function:

void de.zib.vold.frontend.Frontend.insert	(	String	source,
		Key	key,
		Set< String >	value
	)

Insert a key.

Note:: This method is reentrant.

Parameters:

source	The source where the key comes from.
key	The key to insert.
value	The values associated with that key.

Definition at line 145 of file Frontend.java.

References de.zib.vold.common.Key._buildkey(), de.zib.vold.frontend.Frontend.checkState(), de.zib.vold.volatilelogic.SimpleDirectory.insert(), de.zib.vold.frontend.Frontend.log, de.zib.vold.frontend.Frontend.rwlock, and de.zib.vold.frontend.Frontend.volatileDirectory.

Referenced by de.zib.vold.userInterface.ABI.main(), and de.zib.vold.userInterface.RESTController.post().

Here is the call graph for this function:

Here is the caller graph for this function:

Map< Key, Set< String > > de.zib.vold.frontend.Frontend.lookup ( Key key )

Lookup the specified key.

If recursive lookups are enabled , the key will be searched recursive to the root scope until one is found. If prefix lookups are enabled, the suffix "..." indicates a prefix lookup. Lists for search keys given by different hosts are merged.

Definition at line 238 of file Frontend.java.

References de.zib.vold.common.Key._buildkey(), de.zib.vold.frontend.Frontend.checkState(), de.zib.vold.common.Key.get_keyname(), de.zib.vold.common.Key.get_scope(), de.zib.vold.common.Key.get_type(), de.zib.vold.frontend.Frontend.getRecursiveScopeLookups(), de.zib.vold.frontend.Frontend.log, de.zib.vold.frontend.Frontend.rwlock, de.zib.vold.frontend.Frontend.scope_base(), de.zib.vold.frontend.Frontend.scopeLookup(), and de.zib.vold.common.Key.toString().

Referenced by de.zib.vold.userInterface.RESTController.get(), and de.zib.vold.userInterface.ABI.main().

Here is the call graph for this function:

Here is the caller graph for this function:

String de.zib.vold.frontend.Frontend.prepare_prefix_key ( String key ) [private]

Prepare key for (prefix-) lookup.

Removes three dots at the end if they are appended.

Definition at line 120 of file Frontend.java.

Referenced by de.zib.vold.frontend.Frontend.scopeLookup().

Here is the caller graph for this function:

void de.zib.vold.frontend.Frontend.refresh	(	String	source,
		Key	key
	)

Refresh a key.

Parameters:

source	The source for which the keys timestamp should be updated.
key	The key to refresh.

Definition at line 175 of file Frontend.java.

References de.zib.vold.common.Key._buildkey(), de.zib.vold.frontend.Frontend.checkState(), de.zib.vold.frontend.Frontend.log, de.zib.vold.volatilelogic.SimpleDirectory.refresh(), de.zib.vold.frontend.Frontend.rwlock, and de.zib.vold.frontend.Frontend.volatileDirectory.

Referenced by de.zib.vold.userInterface.RESTController.post().

Here is the call graph for this function:

Here is the caller graph for this function:

String de.zib.vold.frontend.Frontend.scope_base ( String scope ) [private]

Get the parent of a scope.

Parameters:

scope The scope to get the parent for.

Returns:: The parent of the scope.

Definition at line 304 of file Frontend.java.

References de.zib.vold.frontend.Frontend.scopeDelimiter.

Referenced by de.zib.vold.frontend.Frontend.lookup().

Here is the caller graph for this function:

Map< Key, Set< String > > de.zib.vold.frontend.Frontend.scopeLookup ( Key key ) [private]

Lookup the specified key only in the given scope.

If prefix lookups are enabled, the suffix "..." indicates a prefix lookup. Lists for Keys given by different hosts are merged;

Exceptions:

VoldException

Definition at line 323 of file Frontend.java.

References de.zib.vold.common.Key._buildkey(), de.zib.vold.common.Key.buildkey(), de.zib.vold.common.Key.get_keyname(), de.zib.vold.common.Key.get_scope(), de.zib.vold.common.Key.get_type(), de.zib.vold.frontend.Frontend.getPrefixLookupsAllowed(), de.zib.vold.frontend.Frontend.log, de.zib.vold.volatilelogic.SimpleDirectory.prefixLookup(), de.zib.vold.frontend.Frontend.prepare_prefix_key(), and de.zib.vold.frontend.Frontend.volatileDirectory.

Referenced by de.zib.vold.frontend.Frontend.lookup().

Here is the call graph for this function:

Here is the caller graph for this function:

void de.zib.vold.frontend.Frontend.setPrefixLookupsAllowed ( boolean prefixLookupsAllowed )

(Do not) allow prefix lookups.

Prefix lookups are indicated by appending three dots ("...") to the key, searched for.

Definition at line 99 of file Frontend.java.

References de.zib.vold.frontend.Frontend.prefixLookupsAllowed.

Referenced by de.zib.vold.frontend.Frontend.Frontend().

Here is the caller graph for this function:

void de.zib.vold.frontend.Frontend.setRecursiveScopeLookups ( boolean recursiveScopeLookups )

Enable/disable recursive scope lookups.

When recursive scope lookups are enabled, a key will be searched not only in the given scope but also in each parent directory, until a result has been found.

Definition at line 80 of file Frontend.java.

References de.zib.vold.frontend.Frontend.recursiveScopeLookups.

Referenced by de.zib.vold.frontend.Frontend.Frontend().

Here is the caller graph for this function:
