de.zib.vold.common.Key Class Reference

A Key as a part of VolD entries. More...

List of all members.

Public Member Functions
	Key (String scope, String type, String keyname) throws IllegalArgumentException
	Construct a Key with all necessary informations.
String	get_scope ()
	Get the scope of the key.
String	get_type ()
	Get the type of the key.
String	get_keyname ()
	Get the name of the key.
String	toString ()
	Convert the key to readable and printable version.
List< String >	_buildkey ()
	Convert the key to the language used in volatilelogic.
boolean	equals (Object obj)
	Compare this key with another key.
int	hashCode ()
	Compute the hash code of this key.
Static Public Member Functions
static Key	buildkey (List< String > key) throws IllegalArgumentException
	Construct a key from list of strings.
Private Attributes
final String	scope
final String	type
final String	keyname

---

Detailed Description

A Key as a part of VolD entries.

A Key is defined by a scope, a type and a keyname. The scope is any valid UNIX-style path. The type and keyname are arbitrary strings.

See also:

URIKey

Definition at line 19 of file Key.java.

---

Constructor & Destructor Documentation

de.zib.vold.common.Key.Key	(	String	scope,
		String	type,
		String	keyname
	)		throws IllegalArgumentException

Construct a Key with all necessary informations.

Parameters:

scope	The scope of the key.
type	The type of the key.
keyname	The name of the key.

Definition at line 28 of file Key.java.

References de.zib.vold.common.Key.equals(), de.zib.vold.common.Key.keyname, de.zib.vold.common.Key.scope, and de.zib.vold.common.Key.type.

Referenced by de.zib.vold.common.Key.buildkey().

Here is the call graph for this function:

Here is the caller graph for this function:

---

Member Function Documentation

List< String > de.zib.vold.common.Key._buildkey

(

)

Convert the key to the language used in volatilelogic.

Returns:

The converted key.

Definition at line 132 of file Key.java.

References de.zib.vold.common.Key.keyname, de.zib.vold.common.Key.scope, and de.zib.vold.common.Key.type.

Referenced by de.zib.vold.frontend.Frontend.insert(), de.zib.vold.frontend.Frontend.lookup(), de.zib.vold.frontend.Frontend.refresh(), de.zib.vold.frontend.Frontend.scopeLookup(), and de.zib.vold.common.Key.toString().

Here is the caller graph for this function:

static Key de.zib.vold.common.Key.buildkey

(

List< String >

key

)

throws IllegalArgumentException [static]

Construct a key from list of strings.

Parameters:

key	The key in a format used in the volatilelogic package.

Returns:

The appropriate Key object.

Definition at line 116 of file Key.java.

References de.zib.vold.common.Key.Key().

Referenced by de.zib.vold.replication.RESTVoldReplicator.insert(), de.zib.vold.replication.RESTVoldReplicator.refresh(), and de.zib.vold.frontend.Frontend.scopeLookup().

Here is the call graph for this function:

Here is the caller graph for this function:

boolean de.zib.vold.common.Key.equals

(

Object

obj

)

Compare this key with another key.

Returns:

true, iff this key represents the same key as obj.

Definition at line 148 of file Key.java.

References de.zib.vold.common.Key.get_keyname(), de.zib.vold.common.Key.get_scope(), and de.zib.vold.common.Key.get_type().

Referenced by de.zib.vold.common.Key.Key().

Here is the call graph for this function:

Here is the caller graph for this function:

String de.zib.vold.common.Key.get_keyname

(

)

Get the name of the key.

Returns:

The name of the key.

Definition at line 95 of file Key.java.

References de.zib.vold.common.Key.keyname.

Referenced by de.zib.vold.client.RESTClient.delete(), de.zib.vold.common.Key.equals(), de.zib.vold.userInterface.RESTController.get(), de.zib.vold.common.Key.hashCode(), de.zib.vold.frontend.Frontend.lookup(), de.zib.vold.userInterface.ABI.main(), de.zib.vold.userInterface.RESTController.post(), de.zib.vold.client.RESTClient.refresh(), de.zib.vold.frontend.Frontend.scopeLookup(), and de.zib.vold.common.URIKey.toURIString().

Here is the caller graph for this function:

String de.zib.vold.common.Key.get_scope

(

)

Get the scope of the key.

Returns:

The scope of the key.

Definition at line 75 of file Key.java.

References de.zib.vold.common.Key.scope.

Referenced by de.zib.vold.client.RESTClient.delete(), de.zib.vold.common.Key.equals(), de.zib.vold.userInterface.RESTController.get(), de.zib.vold.common.Key.hashCode(), de.zib.vold.frontend.Frontend.lookup(), de.zib.vold.userInterface.ABI.main(), de.zib.vold.userInterface.RESTController.post(), de.zib.vold.client.RESTClient.refresh(), de.zib.vold.frontend.Frontend.scopeLookup(), and de.zib.vold.common.URIKey.toURIString().

Here is the caller graph for this function:

String de.zib.vold.common.Key.get_type

(

)

Get the type of the key.

Returns:

The type of the key.

Definition at line 85 of file Key.java.

References de.zib.vold.common.Key.type.

Referenced by de.zib.vold.client.RESTClient.delete(), de.zib.vold.common.Key.equals(), de.zib.vold.userInterface.RESTController.get(), de.zib.vold.common.Key.hashCode(), de.zib.vold.frontend.Frontend.lookup(), de.zib.vold.userInterface.ABI.main(), de.zib.vold.userInterface.RESTController.post(), de.zib.vold.client.RESTClient.refresh(), de.zib.vold.frontend.Frontend.scopeLookup(), and de.zib.vold.common.URIKey.toURIString().

Here is the caller graph for this function:

int de.zib.vold.common.Key.hashCode

(

)

Compute the hash code of this key.

Returns:

The hash code of this key.

Definition at line 175 of file Key.java.

References de.zib.vold.common.Key.get_keyname(), de.zib.vold.common.Key.get_scope(), and de.zib.vold.common.Key.get_type().

Here is the call graph for this function:

String de.zib.vold.common.Key.toString

(

)

Convert the key to readable and printable version.

Returns:

A readable and printable version of the key.

Definition at line 105 of file Key.java.

References de.zib.vold.common.Key._buildkey().

Referenced by de.zib.vold.frontend.Frontend.lookup().

Here is the call graph for this function:

Here is the caller graph for this function:

---

Member Data Documentation

final String de.zib.vold.common.Key.keyname [private]

Definition at line 184 of file Key.java.

Referenced by de.zib.vold.common.Key._buildkey(), de.zib.vold.common.Key.get_keyname(), and de.zib.vold.common.Key.Key().

final String de.zib.vold.common.Key.scope [private]

Definition at line 182 of file Key.java.

Referenced by de.zib.vold.common.Key._buildkey(), de.zib.vold.common.Key.get_scope(), and de.zib.vold.common.Key.Key().

final String de.zib.vold.common.Key.type [private]

Definition at line 183 of file Key.java.

Referenced by de.zib.vold.common.Key._buildkey(), de.zib.vold.common.Key.get_type(), and de.zib.vold.common.Key.Key().

---

The documentation for this class was generated from the following file:

• common/src/main/java/de/zib/vold/common/Key.java
